MAX-E2/841 TEFC SS Low Voltage Normal Thrust with “P” Base

Totally Enclosed Fan Cooled, [HBV_P]

Categories: ,
HP 15 HP through 100 HP
Speed 3600, 1800, 1200 RPM
Voltage 460V
Frequency 60 Hz.


  • Three Phase, 60 Hz, 1.15 Service Factor (Continuous); 50 Hz, 1.0 Service Factor (Continuous)
  • CSA Certified for Class I, Div. 2, Groups B, C, D - Temp Code T3 Minimum
  • Meets or Exceeds IEEE 841 Standards
  • Extended Warranty - 60 Months from Date of Manufacture
  • Class F Insulation
  • Class B Temperature Rise
  • NEMA Design B Torques as a Minimum; Various Ratings also Meet Design C
  • Cast Iron Frame, End Brackets, Fan Cover, Drip Cover and Main Conduit Box
  • Grounding Terminal Inside Main Conduit Box with additional Foot Grounding Provision
  • Oversized Main Conduit Box Rotatable in 90 Degree Increments - F1 Mounted
  • Designed for 50˚C Ambient Temperature
  • Designed for 3300 ft. Elevation
  • Bi-Directional Rotation
  • 1045 Carbon Steel Shaft
  • Aluminum Die Cast Squirrel Cage Rotor Construction
  • Paint System: 2 Part Epoxy
  • Paint Color: Blue - Munsell 5PB 3/8
  • Guide Bearings: 250HP - 400HP Frames are Single Shielded
  • Thrust Bearings: 250HP - 405HP Frames are Re-Greasable Angular Contact with Mobil PolyrexTM EM
  • Automatic Grease Discharge Fittings
  • Cast Iron Inner and Outer Bearing Caps for all frames
  • VBXX INPRO™ Seals Installed on Both Ends
  • Stainless Steel Nameplate and Hardware
  • Stainless Steel Automatic Breather Drain (Located at both End Brackets for Vertical Mounts)
  • New Dual Column Design Nameplate as Standard (60/50 Hz)
  • Suitable for Inverter Use per NEMA MG-, Part 31.
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved
  • 3 Leads Only
  • Vibration Not to Exceed 0.08 Inches Per Second
  • Noise Level Not to Exceed 85 dB(A) at 1 Meter Unloaded
  • NEMA Type P Base
